OptiScan Measurement Tool
Micropol’s optical fiber measurement tool, offers simple and reliable performance verification for communication networks.
Contact us for more information
OptiScan, Micropol’s optical fiber measurement tool, offers simple and reliable performance verification for communication networks. This rugged device checks that each fiber channel meets acceptable attenuation levels, ensuring safe deployment and use.
12 channels simultaneously
Simultaneous testing of up to 12 channels is easily performed by a single operator and takes only seconds, compared to typically 20–25 minutes with conventional optical power meters (OPMs).
OptiScan is a smart and simple assurance for continuous operation and optimal performance in tactical communication networks.
Features
- Fast and reliable functional control of fiber links
- Measure multiple serially connected cables
- Measure up to 12 channels simultaneously
- Supports most popular optical connectors
- Developed and tested together with the Swedish Armed Forces
Specification
| Battery time | 30 hours continuous use (supports simultaneous use and charging) |
| Battery size | 7 Ah |
| Max link no | Up to ~10 cable reels connected in series |
| Channels | Up to 12 channels simultaneously |
| Adapters | 2, 4, or 12 channels |
| Protection | IP65 |
| Temperature range | 0°C to +50°C / +32°F to +122°F |
| Modes | Loop mode (fiber-pair total attenuation) or Link mode (indvidual fiber attenuation) |
| Supported connectors | Most popular technologies including Micropol’s FALCON™/PROCON™, other optical connectors such as HMA, HMC, etc. |
| Voltage | 5 V |
| Laser class | 1 |
| Weight | 772.2g |
